Lutron Homeworks QS Pro LED+ Dimming Module 5A, 230v
LU-LQSE-4A5-230-D
The DIN Power Module (DPM) family is a group of modular products for the control of lighting loads and motor loads.
Features & Benefits
- • Can be used in HomeWorks and HomeWorks QS systems. • Includes QS link for seamless integration of lights and controls. • An auto-detect mode is available to detect and configure forward-phase or reverse-phase (leading-edge or trailing-edge) dimming for incandescent/halogen, electronic/magnetic lowvoltage and neon/cold cathode light sources. • A locked forward-phase or reverse-phase (leadingedge or trailing-edge) mode is available. • Controls dimmable LED loads. Refer to www.lutron.com/ledtool for compatibility with dimmable LED light sources. • RTISS technology compensates for incoming mains voltage variations such as changes in Root Mean Square (RMS) voltage, frequency shifts (up to ± 2% change in frequency /second), harmonics and line noise. • RTISS-TE technology allows for true instantaneous voltage compensation for incoming mains voltage variations. Only operates in reverse-phase (trailingedge) when "voltage-comp." is enabled. • RTISS-ICM technology is able to withstand highinrush LEDs, bulb blowouts, and direct shorts. • Provides air gap off (when all zones are off). • Integral protection for common temporary over-current and over-voltage conditions. • LEDs on the module provide diagnostic information.
