Lutron - lighting control & bespoke blinds
Four Core Blind Cable - 152M
LU-QSH-CBL-M-500
Lutron QSH-CBL-500 16 AWG Core Cable
Variations
Features & Benefits
- Lutron 16 AWG (1.5 mm²) Cable
- Used for Homeworks QS, Grafik Eye QS, Energi Savr Node
- Five conductors:- Common – 16 AWG (1.5 mm²)- Power – 16 AWG (1.5 mm²)- MUX Data – 22 AWG (0.50 mm²)- MUX Data – 22 AWG (0.50 mm²)- Drain Wire – 22 AWG(0.50mm²) Total outer jacket diameter: 0.26 in. (6.6 mm) 300V rated PVC sheath, 90°C rated UL/CSA listed ROHS complian
